AG OFCAS 35
Air compressor
The high quality of the materials combined with cutting-edge technology of the compressor unit, ensure reliability, professionalism and economy and allows continuous use, unthinkable in traditional direct-drive oil-free compressors.
The AirGen OFCAS 35 is the ideal compressor to supply all Zero Air generators ZA FID and ZA Total or the high purity Nitrogen generator NG EOLO.
Product features
- Ultra silent technology: 58 dB(A)
- Oil free
- Low maintenance
- Smooth running – low vibrations
- Compact
- Reliable
- Automatic water purge
Main applications
- Medical laboratories
- Chemical and pharmaceutical industry
- Food factory
- Laser equipments
Technical specifications
| Model: | AG OFCAS 35 |
| General data | |
| Rated power (Max) | 0.75 kW |
| Internal tank capacity | 4 L |
| Dimensions (W x D x H) | 27 x 44 x 41 cm |
| Net weight | 35 kg |
| Noise level | 58dB(A) @ 1.5 m from front |
| Air Outlet | |
| Operation control | Electronic pressure control – Set point with hysteresis |
| Air Delivery (Max) (1) | 35 l/min @ 7Bar |
| Working pressure (min/ Max) | 6bar (87psi) / 8.5bar (123psi) |
| Dew point (2) | < -20°C (<-4°F) |
| Electrical data | |
| Supply rating (3) | 110-120Vac (±10%) @ 50Hz – 115-120Vac (±10%) @ 60 Hz
or 220-240Vac (±10%) @ 50/60 Hz |
| Connection type | IEC320-C14 |
| Nominal power | 750W |
| Fuse rating (5x20mm) | 10A (250Vac – T) |
| Connections | |
| Compressed Air outlet | 1/8” BSPP female fitting |
| Condensate water drain | 1/8” BSPP female fitting |
| Operating/storage conditions | |
| Working Temperature | 5-40°C (41-104°F) |
| Storage Temperature | 1-50°C (34-122°F) |
| Humidity (max, non condensing) | 80% [5-40°C (41-104°F)] |
| Heat value | 2560 |
| IP rating | IP20 |
| Pollution degree rating | 2 (with no aromatic compounds) |
| Altitude | < 2000m |
(1) With supply voltage frequency of 60 Hz
(2) Atmospheric Dew Point (ADP) at 25°C ambient temperature
(3) Adding the suffix “.110” to the standard code configures the unit for 115VAC supply voltage
